Name: County Road Function Class

Display Field: street_name

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN>ABSTRACT</SPAN></P><P><SPAN>The Class B Roads dataset represents known and documented Class B road corridors, historic county roads, and transportation routes associated with Cache County jurisdiction. The dataset serves as a working inventory of roads that have been researched through historical records, surveys, maps, field investigations, and other supporting documentation. The layer is maintained to support county operations, transportation planning, historical preservation, road administration, Class B Road funding activities, and ongoing research related to road status and jurisdiction.</SPAN></P><P><SPAN>LINEAGE</SPAN></P><P><SPAN>The Class B Roads dataset was inherited by the Cache County GIS Division in 2007 upon the formation of the division.</SPAN></P><P><SPAN>The original GIS data was compiled by Larry Brunson and maintained in two primary datasets named "cache_b_Larry" and "FS_Class_B_Roads." These datasets were developed through extensive historical research and were used primarily to support Class B Road funding submissions to the State of Utah. The information was also utilized by Cache County Road Superintendent Darrell Erickson for road administration, maintenance planning, and historical road reference.</SPAN></P><P><SPAN>Following the establishment of the GIS Division, the two datasets were reviewed, reconciled, and merged into a single Class B Roads inventory. Duplicate road segments were evaluated, geometry was refined where appropriate, and attributes were standardized to create a unified countywide dataset.</SPAN></P><P><SPAN>Since 2007, the dataset has been continuously maintained and updated as new information becomes available. Sources used in the development and maintenance of this layer include original federal survey records and field notes dating to the 1850s, General Land Office survey plats, historic maps, aerial photography, county road committee records, county commission records, historical maintenance documentation, road petitions, rights-of-way records, field investigations, GPS observations, consulting surveyor research, retired surveyor interviews, eyewitness accounts, and information provided by long-time residents familiar with historical road alignments.</SPAN></P><P><SPAN>The dataset serves as a catalog of roads associated with historic county transportation corridors, Class B Roads, RS2477 rights-of-way research, and roads that may be subject to current or historical county jurisdiction. Road alignments and attributes are updated as additional evidence is discovered and evaluated.</SPAN></P><P><SPAN>The location and status of some road segments represent the best available interpretation of historical documentation and physical evidence at the time of compilation and may be revised as new information becomes available.</SPAN></P><P><SPAN>DATA QUALITY STATEMENT</SPAN></P><P><SPAN>Positional accuracy varies throughout the dataset due to differences in source material quality, age, and scale. Some road alignments have been verified through modern survey methods, GPS observations, or field investigations, while others are derived from historical maps, survey notes, aerial imagery, or documentary evidence. Users should evaluate the suitability of the data for their intended purpose.</SPAN></P><P><SPAN>USE LIMITATIONS</SPAN></P><P><SPAN>This dataset is intended for informational, planning, research, and administrative purposes only. The inclusion of a road segment within this dataset does not constitute a legal determination of ownership, public access rights, maintenance responsibility, RS2477 status, county jurisdiction, or right-of-way validity. Legal determinations regarding road status, ownership, jurisdiction, or access rights should be made through appropriate legal, surveying, and administrative processes.</SPAN></P></DIV></DIV></DIV>

Copyright Text: Original data compilation believed to be done by Larry Brunson. Larry worked for the Surveyor's Office and Road Department. Dataset maintenance, research, updates, and quality control performed by the Cache County GIS Division. Additional information has been derived from historical records, county departments, consulting surveyors, retired surveyors, road department personnel, state and federal mapping resources, and members of the public.

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 1464921.881250888
YMin: 3668428.06888856
XMax: 1663481.0422026366
YMax: 3892795.606373057
Spatial Reference: 102742  (3560)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [0, 0, 0, 255]
Width: 3
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:
Label Placement: esriServerLinePlacementAboveAlong
Label Expression: N/A
Use Coded Values: true
Symbol:
Color: [230, 152, 0, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 10
Font Family: Tahoma
Font Style: normal
Font Weight: normal
Font Decoration: none

Min. Scale: 215854.47776186772
Max. Scale: 0.0

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: true

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• objectid ( type: esriFieldTypeOID, alias: objectid )
• rin ( type: esriFieldTypeDouble, alias: rin )
• pre_dir ( type: esriFieldTypeString, alias: pre_dir, length: 10 )
• street_name ( type: esriFieldTypeString, alias: street_name, length: 75 )
• common_name ( type: esriFieldTypeString, alias: common_name, length: 75 )
• usfs_rte_no ( type: esriFieldTypeString, alias: usfs_rte_no, length: 20 )
• surface_type ( type: esriFieldTypeString, alias: surface_type, length: 25 )
• network_type ( type: esriFieldTypeString, alias: network_type, length: 25 )
• width_ft ( type: esriFieldTypeDouble, alias: width_ft )
• width_ft_aerial ( type: esriFieldTypeDouble, alias: width_ft_aerial )
• width_ft_shoulder ( type: esriFieldTypeDouble, alias: width_ft_shoulder )
• sq_ft ( type: esriFieldTypeDouble, alias: sq_ft )
• sq_yds ( type: esriFieldTypeDouble, alias: sq_yds )
• row_ft ( type: esriFieldTypeDouble, alias: row_ft )
• recorded_plat ( type: esriFieldTypeString, alias: recorded_plat, length: 15 )
• function_class ( type: esriFieldTypeString, alias: function_class, length: 50 , Coded Values: [Minor Arterial: Minor Arterial] , [Major Collector: Major Collector] , [Minor Collector: Minor Collector] , ...9 more... )
• road_class ( type: esriFieldTypeString, alias: road_class, length: 35 )
• record_of_maintenance ( type: esriFieldTypeString, alias: record_of_maintenance, length: 15 )
• map_years ( type: esriFieldTypeString, alias: map_years, length: 300 )
• comments ( type: esriFieldTypeString, alias: comments, length: 500 )
• juristiction ( type: esriFieldTypeString, alias: juristiction, length: 25 )
• speed_limit ( type: esriFieldTypeString, alias: speed_limit, length: 25 )
• iworqs_alligator ( type: esriFieldTypeSmallInteger, alias: iworqs_alligator )
• iworqs_transverse ( type: esriFieldTypeSmallInteger, alias: iworqs_transverse )
• iworqs_longitudinal ( type: esriFieldTypeSmallInteger, alias: iworqs_longitudinal )
• iworqs_edge ( type: esriFieldTypeSmallInteger, alias: iworqs_edge )
• iworqs_patching ( type: esriFieldTypeSmallInteger, alias: iworqs_patching )
• iworqs_inventory_date ( type: esriFieldTypeDate, alias: iworqs_inventory_date, length: 8 )
• iworqs_current_rsl ( type: esriFieldTypeDouble, alias: iworqs_current_rsl )
• iworqs_last_treatment_date ( type: esriFieldTypeDate, alias: iworqs_last_treatment_date, length: 8 )
• iworqs_last_treatment ( type: esriFieldTypeString, alias: iworqs_last_treatment, length: 50 )
• iworqs_last_rating_date ( type: esriFieldTypeDate, alias: iworqs_last_rating_date, length: 8 )
• iworqs_asset_value ( type: esriFieldTypeDouble, alias: iworqs_asset_value )
• iworqs_recommended_treatment ( type: esriFieldTypeString, alias: iworqs_recommended_treatment, length: 75 )
• iworqs_recommened_treatment_cos ( type: esriFieldTypeDouble, alias: iworqs_recommened_treatment_cos )
• priority_rating_rd_dept ( type: esriFieldTypeSmallInteger, alias: priority_rating_rd_dept )
• priority_rating_chipseal_rd_dep ( type: esriFieldTypeSmallInteger, alias: priority_rating_chipseal_rd_dep )
• created_user ( type: esriFieldTypeString, alias: created_user, length: 255 )
• created_date ( type: esriFieldTypeDate, alias: created_date, length: 8 )
• last_edited_user ( type: esriFieldTypeString, alias: last_edited_user, length: 255 )
• last_edited_date ( type: esriFieldTypeDate, alias: last_edited_date, length: 8 )
• go_away_priority ( type: esriFieldTypeSmallInteger, alias: go_away_priority , Coded Values: [1: 1] , [2: 2] , [3: 3] , ...2 more... )
• function_class_description ( type: esriFieldTypeString, alias: function_class_description, length: 500 )
• road_manual_url ( type: esriFieldTypeString, alias: road_manual_url, length: 150 )
• road_type ( type: esriFieldTypeString, alias: road_type, length: 50 )
• row_type ( type: esriFieldTypeString, alias: row_type, length: 50 )
• summer_maint_grading_yes_no ( type: esriFieldTypeString, alias: summer_maint_grading_yes_no, length: 15 , Coded Values: [YES: YES] , [NO: NO] , [N/A: N/A] )
• summer_maint_grading_cycle ( type: esriFieldTypeString, alias: summer_maint_grading_cycle, length: 50 )
• summer_maint_does_does_not ( type: esriFieldTypeString, alias: summer_maint_does_does_not, length: 20 )
• winter_maint_snowplow_yes_no ( type: esriFieldTypeString, alias: winter_maint_snowplow_yes_no, length: 15 , Coded Values: [YES: YES] , [NO: NO] , [N/A: N/A] )
• winter_maint_snowplow_type ( type: esriFieldTypeString, alias: winter_maint_snowplow_type, length: 50 )
• winter_maint_does_does_not ( type: esriFieldTypeString, alias: winter_maint_does_does_not, length: 20 )
• chipseal_years ( type: esriFieldTypeString, alias: chipseal_years, length: 50 )
• analysis_comments ( type: esriFieldTypeString, alias: analysis_comments, length: 300 )
• gps_median_width_ft ( type: esriFieldTypeInteger, alias: gps_median_width_ft )
• gps_shoulder_width_ft_1 ( type: esriFieldTypeInteger, alias: gps_shoulder_width_ft_1 )
• gps_shoulder_material_1 ( type: esriFieldTypeString, alias: gps_shoulder_material_1, length: 50 )
• gps_shoulder_width_ft_2 ( type: esriFieldTypeInteger, alias: gps_shoulder_width_ft_2 )
• gps_shoulder_material_2 ( type: esriFieldTypeString, alias: gps_shoulder_material_2, length: 50 )
• gps_travel_lane_width_ft_1 ( type: esriFieldTypeInteger, alias: gps_travel_lane_width_ft_1 )
• gps_travel_lane_width_ft_2 ( type: esriFieldTypeInteger, alias: gps_travel_lane_width_ft_2 )
• gps_clearzone_width_ft_1 ( type: esriFieldTypeInteger, alias: gps_clearzone_width_ft_1 )
• gps_clearzone_width_ft_2 ( type: esriFieldTypeInteger, alias: gps_clearzone_width_ft_2 )
• gps_total_width_clear_to_clear ( type: esriFieldTypeInteger, alias: gps_total_width_clear_to_clear )
• adt ( type: esriFieldTypeDouble, alias: adt )
• travel_lanes ( type: esriFieldTypeInteger, alias: travel_lanes )
• class_b_funding_status ( type: esriFieldTypeString, alias: class_b_funding_status, length: 50 )
• inspection_route ( type: esriFieldTypeString, alias: inspection_route, length: 50 )
• gis_miles ( type: esriFieldTypeDouble, alias: gis_miles )
• year_added ( type: esriFieldTypeInteger, alias: year_added )
• year_road_added ( type: esriFieldTypeInteger, alias: year_road_added )
• reason_road_added ( type: esriFieldTypeString, alias: reason_road_added, length: 150 )
• shape ( type: esriFieldTypeGeometry, alias: shape )
• rin_1975 ( type: esriFieldTypeString, alias: rin_1975, length: 15 )
• rin_new ( type: esriFieldTypeString, alias: rin_new, length: 15 )
• st_length(shape) ( type: esriFieldTypeDouble, alias: st_length(shape) )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
